SPECIFICATION OPTICAL PARAMETERS
LED Brand: | CREE,OSRAM |
LED Wattage: | 1W/3W |
Beam Angle: | 8°,15°,30°,45°,60° |
Source Life: | 50,000H |
ELECTRICAL PARAMETERS
Working Voltage: | DC 24V |
Rated Power: | Maximum 3W |
CONTROL PARAMETERS
Control Method: | DMX512/ON-OFF |
CCT/Color: | 2200K-6500K/RGB/RGBW |
Control System: | UKON the lights control system |
STRUCTURAL PARAMETERS
Housing Materials: | Anodised aluminum 6063/ Tempered glass |
Surface Color: | Dark Grey |
Structure Size: | D43*H67mm |
Total Weight: | 221g |
ENVIRONMENTAL PARAMETERS
Working Temperature: | -20°C to 50°C |
Storage Temperature: | -40°C to 70°C |
Humidity Range: | 0%-90% |
Protection Rating: | IP66 |
