SPECIFICATION OPTICAL PARAMETERS
LED Brand: | CREE, Lumileds, Epistar, Osram |
LED Wattage: | 1W |
Beam Angle: | 15°/25°/35°/45°/ 20°x60°/20°x40° |
Source Life: | 50,000H |
ELECTRICAL PARAMETERS
Working Voltage: | DC 24V |
Rated Power: | Maximum 24W |
CONTROL PARAMETERS
Control Method: | DMX512 |
Gray Scale: | RGB/W each 65536 grayscale |
Control System: | UKON the lights control system |
STRUCTURAL PARAMETERS
Shell Material: | Sprayed aluminum housing/ optical glass cover |
Surface Color: | Transparent |
Structure Size: | 35x63.4x1000mm/500mm/300mm |
Total Weight: | 1300g |
ENVIRONMENTAL PARAMETERS
Working Temperature: | -20°C to 50°C |
Storage Temperature: | -40°C to 70°C |
Humidity Range: | 0%-90% |
Protection Rating: | IP66 |
