SPECIFICATION OPTICAL PARAMETERS
LED Brand: | CREE, Lumileds, Epistar, Osram |
LED Wattage:1 | 1W |
Beam Angle: | 14°/10*80° |
Source Life: | 50,000H |
ELECTRICAL PARAMETERS
Working Voltage: | DC 24V |
Rated Power: | Maximum 30W |
CONTROL PARAMETERS
Control Method: | DMX512 |
Gray Scale: | RGB/W each 256 grayscale |
Control System: | UKON the lights control system |
STRUCTURAL PARAMETERS
Shell Material: | Aviation Aluminum 6063/ Toughened safety glass |
Surface Color: | Transparent |
Structure Size: | 98x80x1000mm |
Total Weight: | 4.64kg |
ENVIRONMENTAL PARAMETERS
Working Temperature: | -40°C to 50°C |
Storage Temperature: | -40°C to 70°C |
Humidity Range: | 0%-90% |
Protection Rating: | IP67 |
