SPECIFICATION OPTICAL PARAMETERS
LED Brand: | CREE, Lumileds, Epistar, Osram |
LED Wattage: | 0.3W |
Beam Angle: | 10*60°，30°，45°，60° |
Source Life: | 50,000H |
ELECTRICAL PARAMETERS
Working Voltage: | DC 24V |
Rated Power: | Maximum 24W |
CONTROL PARAMETERS
Control Method: | ON/OFF |
Gray Scale: | / |
Control System: | UKON the lights control system |
STRUCTURAL PARAMETERS
Shell Material: | High Strength Aluminum housing/ tempered glass |
Surface Color: | Transparent |
Structure Size: | 33x60x1000mm/500mm/300mm |
Total Weight: | 1000g |
ENVIRONMENTAL PARAMETERS
Working Temperature: | -20°C to 50°C |
Storage Temperature: | -40°C to 70°C |
Humidity Range: | 0%-90% |
Protection Rating: | IP66 |
