SPECIFICATION OPTICAL PARAMETERS
LED Brand: | CREE,OSRAM |
LED Wattage: | 6W/9W |
Beam Angle: | 6°,10°,20°,30°,45°,60° |
Source Life: | 50,000H |
ELECTRICAL PARAMETERS
Working Voltage: | DC 24V / AC220V |
Rated Power: | Maximum 9W |
CONTROL PARAMETERS
Control Method: | ON-OFF/DMX512 |
STRUCTURAL PARAMETERS
Housing Material: | Anodised Aluminum housing/ tempered glass |
Surface Color: | Black Gray |
Structure Size: | D64.9x87.8mm |
Total Weight: | 650g |
ENVIRONMENTAL PARAMETERS
Working Temperature: | -30°C to 35°C |
Storage Temperature: | -40°C to 70°C |
Humidity Range: | 0%-90% |
Protection Rating: | IP66 |
