SPECIFICATION OPTICAL PARAMETERS
LED Brand: | CREE, Lumileds, Epistar, Osram |
LED Wattage: | 1W |
Beam Angle: | 5° |
Source Life: | 50,000H |
ELECTRICAL PARAMETERS
Working Voltage: | DC 24V |
Rated Power: | Maximum 4W |
CONTROL PARAMETERS
Control Method: | DMX512 |
Gray Scale: | 8Bits/16Bits |
Control System: | UKON the lights control system |
STRUCTURAL PARAMETERS
Shell Material: | High Strength Aluminum housing/ tempered glass |
Surface Color: | Customized |
Structure Size: | 85x85x36mm |
Total Weight: | 150g |
ENVIRONMENTAL PARAMETERS
Working Temperature: | -30°C to 50°C |
Storage Temperature: | -40°C to 70°C |
Humidity Range: | 0%-90% |
Protection Rating: | IP66 |
